Air Compressor Installation Checklist
Technical Guide

Air Compressor Installation Checklist

Technical Article
14 min read
Installation

Condition verification during compressor installation phase directly affects subsequent operating state. Problems missed early on often blow up together during commissioning or operation.

01

Site Conditions

Floor load capacity calculated at 2x equipment weight. This multiplier accounts for dynamic loads from operating vibration. Screw machines have relatively smooth vibration. Piston machine reciprocating inertia forces hit the foundation harder. Foundation treatment methods differ between the two machine types. Flatness deviation controlled within 0.25 inch per 3 feet. Exceeds this range, shim adjustment not enough.

Machine room clear height is equipment height plus 3 feet. This space is for hoisting and overhead piping. If electric hoist or crane is configured, rail elevation and hook travel need to be factored in. Leave 3 feet passage around equipment, 6 feet clear in front of cooling surface. Passage width also needs to consider large component replacement path. Oil separator, cooler cores, these parts aren't small. Need enough operating room during removal and installation.

Entry door width 1.5 feet wider than equipment's largest dimension. Old factory retrofit projects often run into door opening not big enough. Demolishing wall or crane lifting in are both extra cost. This requirement should be coordinated with civil engineering during equipment selection phase.

Corrosive gas environment and flammable/explosive material storage are veto items for machine room location. Near plating shops or pickling tanks, even with good ventilation, not suitable for compressor station.

02

Ventilation Conditions

Intake opening area needs calculation. Heat dissipation, allowable temperature rise, air velocity, plug these parameters into formula. Calculation itself isn't hard. Key is heat dissipation data needs to be accurate. Values marked on equipment samples sometimes correspond to specific conditions. Actual heat generation during full load continuous operation is often higher. Exhaust opening area enlarged to 1.2x intake opening. Machine room forms slight negative pressure state. Hot air exhausts outward instead of circulating inside.

Intake opening location is easier to trip on than area calculation. Position marked on drawings looks reasonable. On-site walkthrough discovers next to it is material yard, machining shop, or boiler room. Dust, oil mist, flue gas, these contamination sources don't show on drawings. Exhaust opening orientation and relationship to adjacent buildings also needs on-site confirmation. High temperature airflow and low frequency noise complaints are troublesome to handle.

Machine room in building interior zone or basement, natural ventilation basically hopeless. Mechanical ventilation becomes standard. Fan selection looks at room volume and air change rate. Fan position and duct routing considered together during layout phase.

03

Electrical Conditions

Power capacity configured at 1.5x equipment power. Current peak during line start reaches several times rated value. This surge needs power capacity to absorb. Models using VFD start or soft start have much gentler starting current. Capacity margin can be tightened accordingly.

Electrical panel

VFD model ground fault protection is a technical detail. VFD output contains high frequency content. Ground leakage current is larger than line frequency equipment. Conventional ground fault protector trip thresholds directly applied often cause nuisance trips. Setting too low affects production. Setting too high weakens protection. This balance point needs to reference VFD manufacturer recommendations combined with on-site testing. Some projects select special protectors that accommodate high frequency leakage current. Solves this problem once and for all.

Independent power disconnect, this requirement looks basic. Easy to be simplified away when multiple equipment share electrical room. Isolating power during maintenance, quick disconnect during emergencies, both depend on this switch.

04

Piping Conditions

Main pipe diameter derived from flow and velocity. Velocity value involves tradeoff between pressure loss and noise. Support spacing tiered by pipe diameter, also considering pipe dead weight and water hammer force.

Pipe installation maintains slope, sloped toward use end or drain point. Compressed air cools and condenses water out. Sections without slope, condensate just pools in low spots and can't drain. Drain valves installed at pipe lowest points. Manual or automatic valve selected based on drainage volume and management approach.

Section valve locations, instrument tap locations nailed down during construction drawing phase. Piping system changes have ripple effects. Supports redone, wall penetrations resealed, insulation restored, bunch of associated work.

05

Water-Cooled Unit Additional Items

Cooling water system looks at flow, temperature, water quality three items. Insufficient flow, heat exchange efficiency won't come up. High water temp, heat exchange temperature differential gets squeezed. Poor water quality, heat exchange surface scales or corrodes. Three parameters are linked. Cooling tower sizing leaves margin. Summer high temps plus tower efficiency degradation, systems without enough margin start getting high temp alarms in July-August. Piping pressure tested for leaks, confirmed leak-free then filled and run.

06

Documents

Unpacking check against packing list. Main unit, motor, control cabinet, accessories, included tools checked item by item. Missing items recorded on the spot. After-the-fact tracing becomes finger pointing.

Product certificate, operating manual, electrical schematic, wear parts list, warranty card filed and stored. Electrical schematic in hand, first compare against actual control cabinet wiring. Batch production models have small version differences. Drawings not keeping up happens occasionally. Wear parts list kept for spare. First time purchasing filter elements, seals, belts, use specs from the list. Avoids wrong part numbers.
